Save 20%DC 12V 24V Stepper Motor Driver Controller Pulse Pwm Signal Generator Module Motor Speed Regulator Frequency Control Module
Product details
SPECIFICATIONS
Brand Name: NONE
Certification: CE
Choice: yes
Color: black
Features 1: Pulse Speed Control Board
Features 2: Pulse Pwm Signal Generate Module
Features 3: motor speed controller
Features 4: Motor Speed Frequency Direction Control
Features 5: Pulse Pwm
Features 6: Stepper Motor Driver Controller
Features 7: Motor Driver Controller electrical tools
High-concerned chemical: None
Model Number: Stepper Motor Driver Controller
Motor: Stepper Motor
Motor Type: Stepper Motor
Origin: Mainland China
Power Supply: DC
semi_Choice: yes
DC 12V 24V Stepper Motor Pulse Signal Generator Module For Stepper Motor Driver Controller Speed Regulator 8-24V
Product description:
This module is a pulse generation module and supplies a stepper driver as a signal.
To control the stepper motor, it must be equipped with a driver.
This simple controller + stepper driver +stepper motor + DC power supply can form a simple control platform.
The controller has a total of 3 kinds of frequency signals: high 5.4k-160khz,medium 540-16.6khz, and low 80-2.4khz,
which can be selected with a jumper.It can generate pulse signal and PWM signal, and it can be selected by jumper.
Frequency measurement:You can measure PUL and common cathode (or common anode) two ports.
Package Included:
1 x Pulse Signal Generator to Stepper Motor Driver Module
